CB1MM5 CONTOUR BRUSH - Passenger Side
SKU Details
| Sku Images | Part# | Description | Diagram Part # | Quantity | ADDTOCARTDETAILSANDPRICE |
|---|---|---|---|---|---|
| CB1B | CONTOUR BRUSH SIDE | - | 1 | ||
| MC1A | LEG | 1 | 4 | ||
| CB1MM5B | FRAME w 8 Round U bolts ½ " | 2 | 1 | ||
| CB2BB-U/L | ARM MOUNT ASSEMBLY | - | 2 | ||
| RB2ABB | Square U-Bolt Fastener set 1/2’’ | - | 4 | ||
| RB2ABB1 | Square U-Bolt 1/2’’x17’’lg | 8.12 | 4 | ||
|
|
SLW12 | Split Lock Washer 1/2” | - | 4 | |
| CB1BBA-U/L | ARM MOUNT PLATE | 5 | 2 | ||
|
|
CB1AC | BUMPER ASSEMBLY | - | 1 | |
|
|
CB1ACA | 2-Piece BUMPER MOUNT (w/Plate welded) | - | 2 | |
| HHCS3816150 | Hex Head Cap Screw 3/8’’-16x1-1/2’’lg | - | 2 | ||
|
|
SLW38 | SPLIT LOCK WASHER 3/8” | 4 | 4 | |
| HN3816 | HEX NUTS 3/8’’ | 2 | |||
| SQHS3816100 | Square Head Screw 3/8”-16x1”lg. | - | 2 | ||
|
|
WA1DBB | Rubber Bumper | - | 4 | |
| HHCS3816125 | Hex Head Cap Screw 3/8” – 16 x 1 ¼” LG | - | 1 | ||
| FW38087 | Flat Washer 3/8” I.D. x 7/8” O.D | - | 4 | ||
| CB1BDAx32 | UPPER ARM w/ distance adjuster | 6 | 2 | ||
| CB1BDBx32 | LOWER ARM w/ distance adjuster- | 7 | 2 | ||
|
|
CB1ADCC | BUSHING for Upper Arm | - | 2 | |
|
|
CB1ADCD | BUSHING for Lower Arm | - | 2 | |
| RB1AE | BRUSH DRIVE LOWER ASSEMBLY | - | 1 | ||
|
|
RB1AEA | MOTOR MOUNT ( 8’’ LG ) | 8 | 1 | |
| HHCS1213300 | Hex Head Cap Screw ½” -13x3”lg. | 9 | 4 | ||
| FW12125 | Flat Washer ½”I.D. x 1 ¼” O.D. | - | 4 | ||
| TB1ADBM | HYDRAULIC MOTOR , displacement 5.0 [cu.in./rev.] | 11 | 1 | ||
| SAE070202-8-8 | Fitting 90° elbow ½” NPTM x ½” JIC | 12 | 2 | ||
| HHCS3816075 | w/Hex Head Screw | - | 4 | ||
|
|
STB-P1X100 | Split Taper Bushing P1 1” | 13 | 1 | |
| SSS1420050C | SPLIT TAPER BUSHING 1” | 2 | |||
|
|
RB2AEB-P1-1-0106 | (set w/two socket set screws ¼ ”-20x ½ ”lg., carbon steel) | 14 | 1 | |
| MC2BBA3-P1-1-0106 | welded weld-on hub | - | 1 | ||
| RB2AE1 | - | - | |||
| HHCS1213125 | Hex Head Screw 3/8’’-16x2’’Lg (Fully threaded, for pillow block adjusted) | 16 | 4 | ||
| RB2AE | BRUSH DRIVE UPPER ASSEMBLY | - | 1 | ||
|
|
RB2AEA | MOTOR MOUNT ( 20’’ lg ) | 17 | 1 | |
| MC2BBA3-P1-1-0106 | w/welded weld-on hub | 14 | 1 | ||
|
|
RB1AF | SHOCK ABSORBER ASSEMBLY | - | 1 | |
| RB1AFA | SPRING SHOCK ABSORBER | 18 | 1 | ||
| RB1AFA1 | UHMW bushing 3/8”I.D | - | 2 | ||
| RB2AFB | Spring adjuster assembly (aluminum 2-piece collar): | 19 | 1 | ||
| RB2AFB1 | Aluminum adjuster (2-piece collar) | - | 1 | ||
| HHCS1420125 | Hex head cap screw ¼” -20 x 1¼”LG. | - | 2 | ||
| HN1420 | Hex nut ¼ ”-20 | - | 2 | ||
| RB1AFC | Plastic spacer | - | 1 | ||
| TB1AEA | PIN Ø 3/8” x 3” LG. | 20 | 2 | ||
|
|
WA1FC | COLLAR 3/8” | - | 2 | |
| RB1AG | FRONT MOUNT: | - | 1 | ||
| WA2GA1 | Clevis | 21 | 1 | ||
| WA2GA2 | Threaded rod ½” -13x5”LG. | 22 | 1 | ||
| WA1GB | Pin 3/8”x1½”lg. | 24 | 1 | ||
|
|
RB1AGA | Shock mount | 26 | 1 | |
| CB1AM-51 | UPPER BRUSH 51” ASSEMBLY: | 27 | 1 | ||
| CB1AMA-51 | Brush Cloth | - | 1 | ||
| CB1AMC-51 | Aluminum Extrusion | - | 2 | ||
| CB1AMB-51 | Two-piece Collar 1½”x12 core | - | 2 | ||
|
|
CB1AM-51 | UPPER 51” ASSEMBLY | 28 | 1 | |
|
|
CB1AMA-51 | Brush Cloth | - | 1 | |
|
|
CB1AMC-51 | Aluminum Extrusion | - | 2 | |
|
|
CB1AMB-51 | Two-piece Collar 1½”x12 core | - | 2 |
